DFU Ball Screw

Product Introduction

Double nuts and single nuts are two types of ball nuts with the same installation dimensions, except for the length. However, the load capacity of double nuts is more than twice that of single nuts. For machinery that requires high rigidity and precise positioning under medium or heavy loads, the DFU Ball Screw, which is a double nut, is suitable.
To achieve this, a significant number of steel balls are positioned between the ball screw and the rolling raceway of the ball nut. These steel balls act as intermediate transmission bodies, facilitating the transformation of sliding contact into rolling contact through the relative movement between the screw and the nut. This not only enhances the load-bearing capabilities but also ensures smoother operation and improved precision in positioning.
In summary, the double nut configuration of the DFU Ball Screw makes it ideal for applications where high rigidity, precise positioning, and efficient load handling are required. By incorporating rolling contact through the use of steel balls, it offers superior performance compared to single nut alternatives.

Product Features

The DFU Ball Screw is designed with a compact structure, making it perfect for applications where space is limited. Its internal circulation design allows for efficient transmission, especially for larger equipment. By utilizing this ball screw, machine utilization can be improved while minimizing tool fatigue and cycle time. Additionally, its high load capacity ensures optimal performance and longevity.

When it comes to precision, our product offers flexibility in choosing the grade that suits your requirements. We have precision options ranging from C7 to C5 to C3, and we also provide the option to customize size specifications based on your specific needs. So whether you require extreme precision or a more general level of accuracy, our product can be tailored to meet your needs.

The versatility of screws is one of their most important traits. With their rich size selection, they can be tailored to suit a variety of applications. Whether you need a screw of specific length, pitch, or diameter, these parameters can easily be customized to meet your requirements and suit a wide range of use cases. In short, the screw's ability to adapt to different needs is a testament to its remarkable flexibility and utility.

Double nut ball screw model

DFU1605, DFU2005, DFU2505, DFU3205, DFU3210, DFU4005, DFU4010, DFU5010, DFU6310, DFU8010 are a series of product codes. These codes represent different models of a certain product.
DFU1605 is the first model in the series. It is followed by DFU2005, DFU2505, DFU3205, DFU3210, DFU4005, DFU4010, DFU5010, DFU6310, and DFU8010.
Each model in this series signifies a unique specification and feature set. The numbers in the code suggest variations and upgrades in different parameters of the product.
It is evident that the series progresses in numerical order, with each subsequent model offering more advanced features compared to its predecessor. These product codes serve as a convenient way to classify and identify the different variants available in the market.
Overall, these DFU codes provide a systematic and organized approach for consumers and manufacturers to navigate through the range of options and select the most suitable product based on their requirements.

Product Specification

Product Application

The use of an ultra-high DN value ball screw has become increasingly prevalent in high-speed machine tools and high-speed comprehensive machining centers. These innovative machines are designed to improve efficiency and productivity in the manufacturing process. With their superior speed and performance, they are capable of achieving exceptional precision and accuracy in even the most complex tasks. The advanced technology behind these ball screws allows for faster and more efficient movement, making them an essential tool for modern machining processes. As a result, they have become a critical component in many industries that require high-quality machining operations.

Ball Screws for End Cap: Ideal for General Industrial Machinery, Automation Machinery, and Quick Handling Systems.

High-speed ball screws are essential components for various types of machinery, including CNC machinery, precision machine tools, industrial machinery, electronic machinery, and high-speed machinery. They play a crucial role in ensuring precise and efficient movement control, making them highly sought-after in the manufacturing industry. With their exceptional speed and accuracy, high-speed ball screws are capable of meeting the demands of modern-day machinery, making them an essential tool for any industrial operation.

Ball screws are widely used in various industries due to their precision and reliability. They play a crucial role in CNC machinery, precision machine tools, industrial machinery, electronic machinery, and conveying machinery. In addition, ball screws are extensively utilized in the aerospace industry, particularly for applications where accuracy and smooth operation are of utmost importance. They are also employed as actuators in antennas and valve switch devices. These versatile components are essential for the efficient functioning of numerous systems and machines, making them indispensable in modern technology.

The Nut Rotary (R1) Series Ball Screws are essential components widely used in various industries such as Semiconductor Machinery, Industrial Robots, Woodworking Machines, Laser Processing Machines, Transfer Devices, and more. These high-quality ball screws play a crucial role in enhancing the efficiency and accuracy of machines and devices.
In Semiconductor Machinery, the Nut Rotary (R1) Series Ball Screws ensure precise positioning and movement, contributing to the seamless operation of semiconductor manufacturing processes. With their reliable performance, they enable the smooth and efficient functioning of intricate systems involved in semiconductor production.
Industrial Robots heavily rely on the Nut Rotary (R1) Series Ball Screws for their precise and smooth motion control. These ball screws enable robots to perform complex tasks with utmost accuracy and repeatability, enhancing productivity and facilitating automation in various industries.
Woodworking Machines benefit from the exceptional precision provided by the Nut Rotary (R1) Series Ball Screws. These ball screws ensure the stability and accuracy required for cutting, shaping, and milling wood materials. As a result, they enable woodworking machines to deliver high-quality outputs in a consistent manner.
Laser Processing Machines extensively utilize the Nut Rotary (R1) Series Ball Screws to achieve precise positioning of laser heads and optical systems. This enables the machines to accurately focus the laser beams on the desired targets, facilitating efficient and effective laser processing operations in industries such as metal fabrication, automotive, and electronics.
Transfer Devices in industries such as logistics and manufacturing utilize the Nut Rotary (R1) Series Ball Screws for smooth and precise movement of materials and components. By ensuring accurate positioning and smooth transfers, these ball screws enhance the overall efficiency and productivity of transfer devices.
In conclusion, the Nut Rotary (R1) Series Ball Screws find extensive applications in various industries, including Semiconductor Machinery, Industrial Robots, Woodworking Machines, Laser Processing Machines, Transfer Devices, and more. Their superior performance and reliability contribute to the improved efficiency, accuracy, and productivity of the machines and devices they are integrated into.

We offer rolled-grade ball screws that provide numerous advantages such as low friction and smooth operation. These ball screws are not only efficient but also deliver exceptional performance. Additionally, we ensure fast delivery and affordable pricing, making them an excellent choice for your needs. So, why wait? Experience the benefits of our rolled-grade ball screws today!

Ball screws are commonly used in a variety of heavy-duty applications such as all-electric injection molding machines, punching machines, semiconductor manufacturing equipment, heavy-duty brakes, industrial machinery, and forging machinery. These robust and durable components play a crucial role in enhancing the efficiency and precision of these machines. Whether it's the smooth operation of an injection molding machine or the precise movements of a punching machine, heavy-duty ball screws ensure reliable performance. Additionally, they are also utilized in semiconductor manufacturing equipment, where precision and accuracy are critical. The robust design of ball screws makes them suitable for heavy-duty braking systems in various industries, including automotive and aerospace. Furthermore, these screws find applications in industrial machinery and forging machinery, contributing to the smooth functioning and productivity of the equipment. Overall, heavy-duty ball screws are essential components that enable the efficient and reliable operation of a wide range of heavy-duty machinery.

When selecting lead screws for equipment, it is important to consider the specific requirements of the machine and choose a screw that is best suited for the job. Avoid blindly pursuing high-precision and high-load screws, which can significantly increase the cost of the equipment. Additionally, the price of a lead screw can vary greatly, so it is important to carefully consider budget constraints and factor in the cost-effectiveness of different options. By carefully selecting the right lead screws, manufacturers can ensure that their equipment operates reliably and efficiently, without breaking the bank.

Our Company

Lishui Hengli Automation Technology Co., Ltd. was founded on December 21, 2010, and has since been providing excellent automation technology consulting and services. Our wide range of offerings include the production and sales of bearings, ball screws, ball screw pairs, linear axes, optical axes, linear guides, linear sliders, sliding tables, support bases, modules, engraving machines, and various accessories. Additionally, we also specialize in automation equipment, accessories, and hardware accessories.
To ensure quick and convenient delivery, we have established overseas warehouses in Europe, Russia, the United States, Brazil, and other locations. This enables us to directly ship products, free from duties and value-added tax. Moreover, our company boasts a highly professional pre-sale and after-sale team, ready to assist our valued customers at every step of the way. You can trust us to provide the utmost support and cooperation. Furthermore, we are approved by the state to engage in the import and export of goods and technologies.
In conclusion, Lishui Hengli Automation Technology Co., Ltd. is a reliable and comprehensive provider of automation solutions. With our extensive product range, efficient delivery system, and dedicated support team, we are committed to meeting the diverse needs of our customers.
